The quest for high-quality p-type doping in β-Ga2O3, a semiconductor material prized for its exceptional thermal conductivity and wide bandgap, has been ongoing for years. While researchers have made progress in addressing the challenge of spontaneous donor defects, achieving reliable p-type doping remains an elusive goal.
A new study published today sheds light on the complexities of p-type doping in β-Ga2O3 by investigating the origin of spontaneous donor defects under different growth conditions. The research team used first-principles computations to analyze the formation of defects in three typical techniques: molecular beam epitaxy (MBE), metal organic chemical vapor deposition (MOCVD), and halide vapor phase epitaxy (HVPE).
The study reveals that the primary donor defects vary depending on the growth method, with Gai3+ dominant in MBE, Hi+ and CGa+ in MOCVD, and (2VGa+Gai+2VO)+ and ClO+ in HVPE. These findings suggest that the choice of growth technique plays a significant role in determining the type and concentration of defects.
To mitigate the issue of spontaneous donor defects, the researchers proposed a theoretically-based voltage-assisted doping method. By applying a suitable voltage, they found that the dominant donors can be significantly reduced, accompanied by an increase in acceptors. This approach allows for a stepwise reduction of the Fermi level, resulting in hole concentrations as high as 8.5 × 10^17 cm^-3 at room temperature without the need for external dopants.
The team also explored the effects of introducing Mg doping on the p-type doping characteristics. By incorporating Mg into the growth process, they observed a further reduction in the Fermi level, indicating improved hole concentration and carrier mobility.
The study’s findings have significant implications for the development of β-Ga2O3-based electronic devices. The ability to control and manipulate spontaneous donor defects could enable the creation of high-quality p-type layers with improved electrical properties. This, in turn, could lead to advancements in power electronics, sensors, and other applications where β-Ga2O3’s unique combination of thermal conductivity and bandgap is valuable.
The research highlights the complex interplay between growth conditions, defect formation, and doping characteristics in β-Ga2O3. As researchers continue to push the boundaries of this material’s potential, a deeper understanding of these interactions will be crucial for achieving reliable p-type doping and unlocking its full capabilities.
Cite this article: “Unlocking P-Type Doping in β-Ga2O3: A Study on Defect Formation and Mitigation Strategies”, The Science Archive, 2025.
